How can I allow this packet(IP 协议,OSPF IGP)

Discussion in 'LnS English Forum' started by wualing, Nov 11, 2007.

Thread Status:
Not open for further replies.
  1. wualing

    wualing Registered Member

    Joined:
    Oct 25, 2007
    Posts:
    3
    look 'n' stop 2.05 and window xp

    How can I allow this packet to downlink!

    11-12-07,02:28:32,UTC,D,0,595,'Block All other packets',0800,142,123.12.29.254,224.0.0.5,89,,
    11-12-07,02:28:33,UTC,D,0,596,'Block All other packets',0800,82,123.12.29.254,224.0.0.5,89,,
    11-12-07,02:28:34,UTC,D,0,597,'Block All other packets',0800,82,123.12.29.1,224.0.0.5,89,,

  2. wualing

    wualing Registered Member

    Joined:
    Oct 25, 2007
    Posts:
    3
    Dose anyone can help me?

  3. Frederic

    Frederic LnS Developer

    Joined:
    Jan 9, 2003
    Posts:
    4,354
    Location:
    France
    Hi,

    You need to create a raw rule by using the RawRuleEdition plugin.
    You can get this plugin fomr there:
    http://www.looknstop.com/En/plugin.htm

    The easiest way to create the rule:
    - by using the standard rule edition create a rule that will catch 47-GRE IP protocol (this one is in the list).
    - then edit the rule with the plugin, and replace the value 47 by 89

    By this way you don't need to understand all the other fields of the RawRuleEdition dialog box, as they have already been set by the standard rule edition.

    Regards,

    Frederic

  4. wualing

    wualing Registered Member

    Joined:
    Oct 25, 2007
    Posts:
    3

    hi,Frederic

    Thanks for you help,my problems are solved!


    Attached Files:

    • GRE.JPG
      File size:
      42.4 KB
      Views:
      103
